Higher Nickel Pipe & Tube
Higher Nickel Pipe & Tube
Higher Nickel Pipes & Tubes are made from a premium combination of nickel and other elements to ensure superior resistance to corrosion, oxidation, and high-temperature conditions. Nickel alloys are known for their strength, durability, and ability to withstand extreme environments, making them the ideal choice for industries like aerospace, chemical processing, and power generation. These pipes and tubes are commonly used in applications where other materials might fail due to harsh conditions, including high temperatures, pressure, and corrosive atmospheres. Nickel-based alloys like Inconel, Monel, and Hastelloy are prime examples of materials used for manufacturing these high-performance pipes and tubes.
Known for their remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, Higher Nickel Pipes & Tubes offer long service lives, even in the harshest environments. They are ideal for handling both acidic and alkaline solutions, with their resistance to many chemicals making them suitable for use in various industries such as petrochemicals, chemical plants, and marine engineering. Whether you're working with seawater, sulfuric acid, or other aggressive substances, higher nickel alloys provide the durability and performance required to maintain safety and efficiency in challenging conditions.
Specification Table
| Specification | Grade | Size Range | Wall Thickness | Standard |
|---|---|---|---|---|
| ASTM B163 | Inconel 600 | 1/2" to 24" | Sch 10S to Sch 160 | ASME, ASTM |
| ASTM B164 | Monel 400 | 1/2" to 12" | Sch 10S to Sch 40S | ISO, ASTM, ASME |
| ASTM B575 | Hastelloy C-276 | 1/4" to 12" | Sch 5S to Sch 160 | ASTM, ASME, DIN |
| ASTM B730 | Inconel 625 | 1/4" to 36" | Sch 40S to Sch 160 | ASTM, ASME |
Grade Comparison Table
| Grade | Composition | Common Applications | Corrosion Resistance |
|---|---|---|---|
| Inconel 600 | Ni: 72%, Cr: 14-17%, Fe: 6-10% | Aerospace, chemical processing, furnace components | Excellent resistance to oxidation, carburization, and sulfidation at high temperatures |
| Monel 400 | Ni: 63%, Cu: 28%, Fe: 2.5% | Marine environments, chemical processing, valves, pumps | Outstanding resistance to seawater and marine corrosion, resistant to a wide range of acids |
| Hastelloy C-276 | Ni: 57%, Mo: 15-17%, Cr: 14.5-16.5% | Chemical plants, nuclear reactors, pollution control equipment | Exceptional resistance to corrosion in a wide range of aggressive media, especially chlorine and sulfuric acid |
| Inconel 625 | Ni: 58%, Cr: 20%, Mo: 9% | Aerospace, marine engineering, chemical processing, heat exchangers | Superior resistance to high-temperature oxidation and corrosion in aggressive environments |
Client Comments
-
James Carter
We used Inconel 600 pipes from Stellirox Tubular LLP for a high-temperature industrial furnace project. These pipes performed excellently, maintaining strength and resistance to oxidation at temperatures over 1000°F. A highly reliable product.
-
Olivia Williams
We sourced Monel 400 tubes from Stellirox Tubular LLP for our marine seawater system. The material’s exceptional resistance to seawater corrosion and pitting is exactly what we needed. The project was completed on time with no issues.
-
David Thompson
We used Hastelloy C-276 pipes from Stellirox Tubular LLP for a highly corrosive chemical processing application. These pipes handled the harsh chemical environment perfectly and showed no signs of corrosion or degradation even after extended use.
-
Sophia Martinez
We used Inconel 625 welded tubes from Stellirox Tubular LLP for our power generation systems. The material exhibited outstanding resistance to high-temperature oxidation and performed superbly in critical applications.
Key Features- High Temperature Resistance: Nickel alloys perform well in high-temperature environments, maintaining strength and resisting oxidation.
- Corrosion Resistance: Excellent resistance to corrosion from chemicals, seawater, and high-stress environments.
- Good Weldability: Higher nickel alloys are highly weldable, offering strong joints without compromising integrity.
- Durability: Known for their durability, these pipes and tubes offer long service life even in extreme conditions.
- Versatility: Suitable for a wide range of applications, including aerospace, chemical processing, and marine engineering.
- Resistant to Pitting and Stress Corrosion Cracking: Nickel-based alloys prevent pitting and cracking under stress, making them ideal for aggressive media.
